Compare
the pathological image-left and the physiological image-right
(blinded) <<
F:
Neither stenosis nor
occlusion of the renal artery was detected - but there is a common
anatomical variation in the origin of the right hepatic artery
H:
Adult man, 41-years-old,
hypertension. - The patient is suspected of having renal artery stenosis.
INFO/WWW:
In about 30% of the patients the right hepatic artery arises from the superior
mesenteric artery. In some cases the superior mesenteric artery may provide
the total hepatic arterial supply.
D:
Renal artery stenosis
was excluded - but there is a common anatomical variation: the right hepatic
artery arises from the superior mesenteric artery
IN
THIS PART OF THE PAGE YOU FIND SOME TEXT FIELDS WHICH CAN BE OPENED EIGTHER
STEP BY STEP (CLICK ON "HISTORY", "HELP", "FINDINGS",
"DIAGNOSIS" OR "INFO/WWW-LINKS") OR AT ONCE WITH A CLICK
ON "ALL ON" - VICE VERSA CLICK ON "ALL OFF".
If you need
a physiological image to compare click here
